      Sensedge Go Gateway Mounting Guide


      The Kaiterra Sensedge Go Gateway ships with a mounting bracket.

      To mount the Gateway, you will need

      • The Gateway
      • Mounting Bracket
      • Four #6 screws, with anchors (not provided)
      • Screwdriver
      • Drill

      Determining Location

      • For optimal performance, place the Gateway at a level higher than the Go devices.
      • Angle the antenna so it is not parallel to the surface. It does not need to be perpendicular to the surface, but it should not be flat.



      • Select a location central to all devices to be connected to this Gateway.
      • Avoid obstructions as much as possible.

      Important: Thick walls and reflective surfaces, such as metal, weaken the signal between the Gateway and the Go devices. We recommend conducting a site survey to test the signal strength in different locations before you mount the Gateway.

      Mounting the Gateway

      1. Determine where you want to mount the device.

      2. Hold up the backplate and mark where you want the screws to go.

      1. Drill holes for the screws and insert anchors.
      2. Place the mounting bracket and secure it with the screws.
      3. Attach the device to the bracket and rotate until it locks into place.
